Search By Code 560914C

Part number: 560914C

Availability:
Price:
Description:
Brake Drum
Replaced:

560914
Inner brake drum diameter [mm]
268,1
Inner Brake Drum Height [mm]
68,5
Outer brake drum diameter [mm]
311
Total Br. Drum Height [mm]
88
Hole Arrangement/Number
05/09
Bolt Hole Circle Ø [mm]
112
Centering Diameter [mm]
68,1
Max.skimmed drum measure [mm]
269,5
Number of Holes
5
Surface
Painted
Barcode:
8052553581699
WARRANTY INFO:
2 YEARS

701609617 (AUDI)
701609617 (SEAT)
701609617 (SKODA)
701609617 (VW)

Applications

Description	KW	CCM	Cylinders	from/to	Engine code	power supply
VW TRANSPORTER IV Autobus (70XB, 70XC, 7DB, 7DW) 1.8	49	1781	4	12-1990/07-1992	PD	Benzina

VW TRANSPORTER IV Autobus (70XB, 70XC, 7DB, 7DW) 1.9 D	44	1896	4	09-1990/12-1995	1X	Diesel

VW TRANSPORTER IV Autobus (70XB, 70XC, 7DB, 7DW) 1.9 D	45	1896	4	09-1990/12-1995	1X	Diesel

VW TRANSPORTER IV Autobus (70XB, 70XC, 7DB, 7DW) 1.9 TD	50	1896	4	10-1992/04-2003	ABL	Diesel

VW TRANSPORTER IV Autobus (70XB, 70XC, 7DB, 7DW) 2.0	62	1968	4	09-1990/04-2003	AAC	Benzina

VW TRANSPORTER IV Autobus (70XB, 70XC, 7DB, 7DW) 2.4 D	57	2370	5	09-1990/04-1998	AAB	Diesel

VW TRANSPORTER IV Autobus (70XB, 70XC, 7DB, 7DW) 2.4 D Syncro	57	2370	5	10-1992/09-1998	AAB	Diesel

VW TRANSPORTER IV Autobus (70XB, 70XC, 7DB, 7DW) 2.5	81	2461	5	09-1990/06-2003	AAF	Benzina

VW TRANSPORTER IV Autobus (70XB, 70XC, 7DB, 7DW) 2.5 Syncro	81	2461	5	08-1992/04-2003	AAF	Benzina

VW TRANSPORTER IV Autobus (70XB, 70XC, 7DB, 7DW) 2.5 TDI	75	2461	5	09-1995/04-2003	ACV	Diesel

VW TRANSPORTER IV Autobus (70XB, 70XC, 7DB, 7DW) 2.8 VR 6	103	2792	6	11-1995/04-2000	AES	Benzina

VW TRANSPORTER IV Furgonato (70XA) 1.9 D	44	1896	4	09-1990/12-1995	1X	Diesel

VW TRANSPORTER IV Furgonato (70XA) 1.9 D	45	1896	4	07-1990/12-1995	1X	Diesel

VW TRANSPORTER IV Furgonato (70XA) 1.9 TD	50	1896	4	10-1992/04-2003	ABL	Diesel

VW TRANSPORTER IV Furgonato (70XA) 2.0	62	1968	4	07-1990/04-2003	AAC	Benzina

VW TRANSPORTER IV Furgonato (70XA) 2.4 D	57	2370	5	07-1990/04-1998	AAB	Diesel

VW TRANSPORTER IV Furgonato (70XA) 2.4 D Syncro	57	2370	5	10-1992/09-1998	AAB	Diesel

VW TRANSPORTER IV Furgonato (70XA) 2.5	81	2461	5	11-1990/04-2003	AAF	Benzina

VW TRANSPORTER IV Furgonato (70XA) 2.5 Syncro	81	2461	5	01-1996/11-2001	AAF	Benzina

VW TRANSPORTER IV Furgonato (70XA) 2.5 TDI	75	2461	5	09-1995/04-2003	ACV	Diesel

VW TRANSPORTER IV Furgonato (70XA) 2.5 TDI Syncro	75	2461	5	09-1995/04-2003	ACV	Diesel

VW TRANSPORTER IV Pianale piatto/Telaio (70XD) 1.9 D	44	1896	4	09-1990/12-1995	1X	Diesel

VW TRANSPORTER IV Pianale piatto/Telaio (70XD) 1.9 D	45	1896	4	07-1990/12-1995	1X	Diesel

VW TRANSPORTER IV Pianale piatto/Telaio (70XD) 1.9 TD	50	1896	4	10-1992/04-2003	ABL	Diesel

VW TRANSPORTER IV Pianale piatto/Telaio (70XD) 2.0	62	1968	4	07-1990/04-2003	AAC	Benzina

VW TRANSPORTER IV Pianale piatto/Telaio (70XD) 2.4 D	57	2370	5	09-1990/04-1998	AAB	Diesel

VW TRANSPORTER IV Pianale piatto/Telaio (70XD) 2.4 D Syncro	57	2370	5	10-1992/09-1998	AAB	Diesel

VW TRANSPORTER IV Pianale piatto/Telaio (70XD) 2.5	81	2461	5	11-1990/04-2003	AAF	Benzina

VW TRANSPORTER IV Pianale piatto/Telaio (70XD) 2.5 Syncro	81	2461	5	11-1992/11-2001	AAF	Benzina

VW TRANSPORTER IV Pianale piatto/Telaio (70XD) 2.5 TDI	75	2461	5	09-1995/04-2003	ACV	Diesel
